W/Automatic Transmission

Fig. 2 Engine Mounts. Models w/Auto. Trans.:

LH INSULATOR & SUPPORT ASSEMBLY

1. Raise and support vehicle, then remove left front wheel and tire assembly.
2. Support transmission with suitable jack and block of wood positioned near insulator.
3. Remove insulator to support assembly attaching nuts, Fig. 2.
4. Remove insulator to frame through bolts, then using jack, raise transmission enough to unload insulator.
5. Remove support assembly to transmission attaching bolts, then remove insulator and/or transmission support assembly.
6. Reverse procedure to install.

RH FRONT OR REAR INSULATOR

1. Remove lower damper nut from right side of engine.
2. Raise and support vehicle, then support engine with suitable jack and block of wood positioned near insulator.
3. Remove insulator to frame attaching nut, Fig. 2, then raise engine enough to unload insulator.
4. Remove insulator to engine bracket attaching bolts, then the insulator.
5. Reverse procedure to install.
