Solenoid-Battery Coolant Valve (Standard) Connector End View (D2815A)

Harness-Family: Motor

Color: BLACK

Gender: FEMALE

Part Number: 15365708

Part Description: Not Available

Connector No: D2815A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Solenoid-Battery Coolant Valve Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Solenoid-Battery Coolant Valve Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

H370

0.50

BATTERY COOLANT VALVE CONTROL

N/A

Z910

BK/GN

0.50

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
