Motor-Park Pawl (Standard) Connector End View (D2814A)

Harness-Family: Motor

Color: BROWN

Gender: FEMALE

Part Number: 13846922

Part Description: Not Available

Connector No: D2814A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Motor-Park Pawl Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Motor-Park Pawl Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

T376

YE/DB

0.50

QUADRETURE SENSOR 1 SIGNAL

N/A

T377

YE/VT

0.50

QUADRETURE SENSOR 2 SIGNAL

N/A

H25

GN/WH

1.5

MOTOR (-)

N/A

H26

GN/RD

1.5

MOTOR (+)

N/A

T192

VT/YE

0.50

SENSOR GROUND

N/A

F893

0.50

5 VOLT SUPPLY

N/A

⁽¹⁾	Pins not listed are not used for this connector
