Heater-Seat Cushion-Left (Standard) Connector End View (D6718)

Harness-Family: Seat_Driver

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 7283-6443-40

Part Description: Not Available

Connector No: D6718

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Heater-Seat Cushion-Left Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Heater-Seat Cushion-Left Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

F37

1.0

SEAT SWITCH IGNITION

N/A

Z916

RD/WH

1.0

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
