Antenna-Satellite Radio (Standard) Connector End View (D5928)

Harness-Family: Body_Rear

Color: BLACK

Gender: MALE

Part Number: 21 ARC 0-0-1K1

Part Description: Not Available

Connector No: D5928

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Antenna-Satellite Radio Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Antenna-Satellite Radio Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

D126

999

SATELLITE RADIO ANTENNA SHIELD

N/A

D106

10.0

SATELLITE RADIO ANTENNA SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
