Airbag-Side Curtain-Right (Standard) Connector End View (D3084)

Harness-Family: Body_Rear

Color: BLACK

Gender: FEMALE

Part Number: 13824818

Part Description: Not Available

Connector No: D3084

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Airbag-Side Curtain-Right Connector End View (Standard)
GCWD1081666Courtesy of CHRYSLER
Fig 2: Airbag-Side Curtain-Right Component Location (Standard)
GCWD1264785Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 R2 WH 0.50 RIGHT CURTAIN SQUIB 1 LINE 2 N/A
2 R4 DG 0.50 RIGHT CURTAIN SQUIB 1 LINE 1 N/A
(1) Pins not listed are not used for this connector
