Airbag-Side Curtain-Left (Standard) Connector End View (D3083)

Harness-Family: Body_Rear

Color: BLACK

Gender: FEMALE

Part Number: 13966981

Part Description: Not Available

Connector No: D3083

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Airbag-Side Curtain-Left Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Airbag-Side Curtain-Left Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

0.50

LEFT CURTAIN SQUIB 1 LINE 2

N/A

0.50

LEFT CURTAIN SQUIB 1 LINE 1

N/A

⁽¹⁾	Pins not listed are not used for this connector
