Heater-Battery Coolant C2 (Standard) Connector End View (D2750B)

Harness-Family: Motor

Color: BLACK

Gender: FEMALE

Part Number: 13738743

Part Description: Not Available

Connector No: D2750B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Heater-Battery Coolant C2 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Heater-Battery Coolant C2 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

T347

BN/OG

0.50

HIGH VOLTAGE INTERLOCK SAFETY LOOP 3

N/A

T343

BN/OG

0.50

HIGH VOLTAGE INTERLOCK SAFETY LOOP 7

N/A

⁽¹⁾	Pins not listed are not used for this connector
