Electric Air Heater C4 (Standard) Connector End View (D6715D)

Harness-Family: Ground_Jumper

Color: NA

Gender: FEMALE

Part Number: 2014

Part Description: Not Available

Connector No: D6715D

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Electric Air Heater C4 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Electric Air Heater C4 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z802

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
