S1007 (Standard) Connector End View (S1001EJ)

Harness-Family: Injector

Color: NA

Gender: FEMALE

Part Number: AGV36375

Part Description: Not Available

Connector No: S1001EJ

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: S1007 Connector End View (Standard)

GCWD1006420

Courtesy of CHRYSLER

Fig 2: S1007 Component Location (Standard)

GCWD1247096

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

F343

DB/RD

0.75

FUSED ASD RELAY OUTPUT

N/A

2

F343

DB/RD

0.75

FUSED ASD RELAY OUTPUT

N/A

3

F343

DB/RD

0.75

FUSED ASD RELAY OUTPUT

N/A

4

F343

DB/RD

0.75

FUSED ASD RELAY OUTPUT

N/A

5

F343

DB/RD

0.75

FUSED ASD RELAY OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
