Lamp-Courtesy-Left Front Door (Standard) Connector End View (D4640A)

Harness-Family: Door_Front_Left

Color: BLACK

Gender: FEMALE

Part Number: 2138557-1

Part Description: Not Available

Connector No: D4640A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Lamp-Courtesy-Left Front Door Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Lamp-Courtesy-Left Front Door Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

M59

YE/GN

0.5

COURTESY LAMP FEED

N/A

Z941

0.5

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
