Antenna-Am/Fm (Std) Connector End View (D5900A)

Harness-Family: Body_Rear

Color: CURRY

Gender: MALE

Part Number: 1/13061/81

Part Description: Not Available

Connector No: D5900A

Option: STD

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Antenna-Am/fm Connector End View (STD)

Courtesy of CHRYSLER

Fig 2: Antenna-Am/fm Component Location (STD)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

0.81

ANTENNA SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
