Actuator-RECIRCULATION Door (Standard) Connector End View (D10A)

Harness-Family: HVAC

Color: BLACK

Gender: FEMALE

Part Number: 1355082-1

Part Description: Not Available

Connector No: D10A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Actuator-Recirculation Door Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Actuator-Recirculation Door Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

C268

WH/RD

0.35

RECIRCULATION DOOR DRIVER

N/A

C68

GN/WH

0.35

RECIRCULATION DOOR COMMON DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
