Speaker-Right Rear Door (Standard) Connector End View (D5911A)

Harness-Family: Door_Rear_Left

Color: BLACK

Gender: FEMALE

Part Number: 1/10275/87

Part Description: Not Available

Connector No: D5911A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Speaker-Right Rear Door Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Speaker-Right Rear Door Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

X205

0.75

LEFT REAR SPEAKER (+)

N/A

X295

GN/BK

0.5

LEFT REAR SPEAKER (-)

N/A

⁽¹⁾	Pins not listed are not used for this connector
