Shield, Underbody: Removal

WARNING: This page is about a different variant/trim than selected.
GC0157896Courtesy of CHRYSLER GROUP, LLC
  1. Raise and support the vehicle. Refer to HOISTING .
  2. Remove the four fasteners that secure the underbody shield to the battery.
  3. Remove the four fasteners that secure the underbody shield to the floor.
  4. Remove the underbody shield from the vehicle.
