DECKLID/Hatch/Liftgate/Tailgate/Swing Gate: Striker: Removal

GC0153189Courtesy of CHRYSLER GROUP, LLC
  1. Open the liftgate.
  2. Mark the position of the striker (1) on the liftgate opening lower panel to aid installation.
  3. Remove the two screws (4) that secure the striker to the lower panel and remove the striker.
