Engine Temperature
The standard equipment engine temperature gauge is located above the upper right side of the electronic display unit (also known as the Electronic Vehicle Information Center/EVIC), located in the center of the Instrument Cluster (IC) (also known as the Instrument Panel Cluster/IPC). This gauge consists of a bar graph that reads from left to right. An International Control and Display Symbol icon for Engine Coolant Temperature is located near the bottom of the gauge. Refer to INTERNATIONAL VEHICLE CONTROL AND DISPLAY SYMBOLS, DESCRIPTION .
The engine coolant temperature gauge is serviced as a unit with the IC.
