Tube, Fuel Tank Filler: Installation: Installation

WARNING: This page is about a different car, the 2015 Fiat 500. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Fuel Tank, Filler Tube, Connector Hose, Clamp & Bolt
GC0152392Courtesy of CHRYSLER GROUP, LLC
  1. Position the fuel connector hose to the fuel filler tube.
  2. Position the fuel filler tube to the filler inlet on the vehicle body.
  3. Install the connector hose (5) to the fuel tank inlet (4).
  4. Install the filler tube stabilizer bracket bolt (2). Tighten bolt to 9 N.m (80 in lbs.).
  5. Tighten the clamps to the connector hose.
    Fig 2: Filler Tube, Gas Cap & Screws
    GC0152391Courtesy of CHRYSLER GROUP, LLC
  6. Install the screws (2) that secure the filler tube to the body.
    Fig 3: Splash Shield To Bodyside Fasteners
    GC0153069Courtesy of CHRYSLER GROUP, LLC
    NOTE:

    Left rear splash shield shown in illustration, right rear splash shield similar.

  7. Install the right rear wheel splash shield. Refer to SHIELD, SPLASH, REAR WHEELHOUSE, INSTALLATION .
  8. Lower the vehicle.
  9. Install the fuel filler cap.
  10. Connect the negative battery cable and tighten nut to 5 N.m (45 in. lbs.).
