Pick-Up, Oil Pump: Installation: Installation
WARNING: This page is about a different car, the 2015 Fiat 500. However, it is still accessible from the selected car via links, so may be relevant.
- Lightly lubricate the new O-ring seal (1) with engine oil and install on the oil pump.
- Install the oil pick-up tube (1) with two bolts (2). Tighten the bolts to 10 N.m (89 in. lbs.).
- Install the oil pan. Refer to PAN, OIL, INSTALLATION .
- If removed, install the oil filter and fill the engine crankcase with the proper oil to the correct level. Refer to STANDARD PROCEDURE .
- Connect the negative battery cable and tighten nut to 5 N.m (45 in. lbs.).
- Run the engine until it reaches normal operating temperature.
