Connector End Views & Electrical Component Locations (2 Of 3): Relay-Horn

Harness-Family: PDC_Underhood

Color: NA

Gender: MALE

Part Number: RELAY_MICRO

Part Description: Not Available

Connector No: R0826

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: Relay-Horn Connector End View

Courtesy of CHRYSLER

Fig 2: Relay-Horn Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

LG/WT

0.35

HORN RELAY CONTROL

STANDARD

INTERNAL

HORN RELAY CONTROL

STANDARD

A904

RD/YL

1.5

FUSED B(+)

STANDARD

⁽¹⁾	Pins not listed are not used for this connector
