Relay-HVAC Blower/Power Outlet

Harness-Family: PDC_Underhood

Color: NA

Gender: MALE

Part Number: RELAY_MICRO

Part Description: Not Available

Connector No: R0876A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: Relay-Hvac Blower/power Outlet Connector End View

Courtesy of CHRYSLER

Fig 2: Relay-Hvac Blower/power Outlet Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z910

0.5

GROUND

STANDARD

F942

GY/WT

0.5

FUSED IGNITION SWITCH OUTPUT (RUN-START)

STANDARD

⁽¹⁾	Pins not listed are not used for this connector
