Relay-Fuel Pump

Harness-Family: PDC_Underhood

Color: NA

Gender: MALE

Part Number: RELAY_MICRO

Part Description: Not Available

Connector No: R0823

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: Relay-Fuel Pump Connector End View

GCWD1006402

Courtesy of CHRYSLER

Fig 2: Relay-Fuel Pump Component Location

GCWD1166103

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

30

N1

VT/YL

2.5

FUEL PUMP CONTROL OUTPUT

STANDARD

85

Z910

BK

0.5

GROUND

STANDARD

86

K31

WT/LG

0.35

FUEL PUMP CONTROL

STANDARD

87

N1

LG/OR

2.5

FUEL PUMP CONTROL OUTPUT

STANDARD

⁽¹⁾	Pins not listed are not used for this connector
