Relay-After Run Pump

Harness-Family: PDC_Underhood

Color: NA

Gender: MALE

Part Number: RELAY_MICRO

Part Description: Not Available

Connector No: R0833A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: Relay-After Run Pump Connector End View

GCWD1006402

Courtesy of CHRYSLER

Fig 2: Relay-After Run Pump Component Location

GCWD1165918

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

30

K548

RD/LG

0.5

ELECTRIC COOLANT PUMP OUTPUT

STANDARD

85

K502

WT/RD

0.35

ELECTRIC COOLANT PUMP CONTROL

STANDARD

86

A955

RD/WT

0.5

ASD RELAY OUTPUT

STANDARD

87

A955

RD/WT

0.5

ASD RELAY OUTPUT

STANDARD

⁽¹⁾	Pins not listed are not used for this connector
