Relay-A/C Clutch

Harness-Family: PDC_Underhood

Color: NA

Gender: MALE

Part Number: RELAY_MICRO

Part Description: Not Available

Connector No: R0819

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: Relay-A/C Clutch Connector End View

GCWD1006402

Courtesy of CHRYSLER

Fig 2: Relay-A/C Clutch Component Location

GCWD1166114

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

30

C3

RD/BR

0.75

A/C CLUTCH CONTROL OUTPUT

STANDARD

85

C13

YL/DB

0.35

A/C CLUTCH CONTROL

STANDARD

86

F307

DB/BK

0.35

FUSED IGNITION RUN/ACCESSORY CONTROL OUTPUT

STANDARD

87

C3

BR/BK

0.5

A/C CLUTCH CONTROL OUTPUT

STANDARD

⁽¹⁾	Pins not listed are not used for this connector
