Solenoid-Key Lock

Harness-Family: Body_Front

Color: WHITE

Gender: FEMALE

Part Number: FJH73292

Part Description: Not Available

Connector No: D0007

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: ~~

Fig 1: Solenoid-Key Lock Connector End View

GCWD1082180

Courtesy of CHRYSLER

Fig 2: Solenoid-Key Lock Connector Location View

GCWD1187453

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	Z910	BK	22	GROUND	N/A
2	K320	BR	22	KEY LOCK SOLENOID SIGNAL	N/A
