Sensor-Occupant Detection

Harness-Family: Seat_Pass

Color: BLACK

Gender: MALE

Part Number: 7122-8326-30

Part Description: SDL CONNECTOR HOUSING

Connector No: D2457A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Sensor-Occupant Detection Connector End View
GCWD1006284Courtesy of CHRYSLER
Fig 2: Sensor-Occupant Detection Connector Location View
GCWD1187485Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 R283 LG 20 PASSENGER SEAT OCCUPANT DETECTION SIGNAL N/A
2 Z927 LG 20 GROUND N/A
