Sensor-Engine Oil Temperature

Harness-Family: Engine

Color:

Gender: FEMALE

Part Number: AGV67596

Part Description: Not Available

Connector No: D1544

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: Sensor-Engine Oil Temperature Connector End View
GCWD1090814Courtesy of CHRYSLER
Fig 2: Sensor-Engine Oil Temperature Connector Location View
GCWD1187475Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 G24 YL 20 EOT SIGNAL N/A
2 K900 BR 20 SENSOR GROUND N/A
