Relay-HVAC Blower

Harness-Family: PDC_Underhood

Color: NA

Gender: MALE

Part Number: Relay_Micro

Part Description: Not Available

Connector No: R0876

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: Relay-HVAC Blower Connector End View

GCWD1006402

Courtesy of CHRYSLER

Fig 2: Relay-HVAC Blower Connector Location View

GCWD1187486

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
85	F103	INTERNAL	NA	IGNITION RUN/ACC RELAY CONTROL	N/A
86	Z910	INTERNAL	NA	GROUND	N/A
87	A938	INTERNAL	NA	SWITCHED B(+)	N/A
