Relay-Cigar Lighters

Harness-Family: PDC_Underhood

Color: NA

Gender: MALE

Part Number: Relay_Micro

Part Description: Not Available

Connector No: R0030

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: Relay-Cigar Lighters Connector End View

Courtesy of CHRYSLER

Fig 2: Relay-Cigar Lighters Connector Location View

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
30	A207	INTERNAL	NA	FUSED B(+)	N/A
85	Z910	INTERNAL	NA	GROUND	N/A
86	F103	INTERNAL	NA	IGNITION RUN/ACC RELAY CONTROL	N/A
87	A205	INTERNAL	NA	FUSED B(+)	N/A
