Fuse F31 7.5A

Harness-Family: PDC_2

Color: NA

Gender: MALE

Part Number: Fuse-Ckt_Breaker

Part Description: Not Available

Connector No: F0031

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: Fuse F31 7.5a Connector End View

GCWD1006305

Courtesy of CHRYSLER

Fig 2: Fuse F31 7.5a Connector Location View

GCWD1187812

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	F100	INTERNAL	NA	FUSED IGNITION RUN CONTROL OUTPUT	N/A
2	F103	INTERNAL	NA	IGNITION RUN/ACC RELAY CONTROL	N/A
