Blunt Cut 4

Harness-Family: Engine_8V

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: L8004

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: Blunt Cut 4 Connector End View

GCWD1006457

Courtesy of CHRYSLER

Fig 2: Blunt Cut 4 Connector Location View

GCWD1187478

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	K147	BK	20	KNOCK SENSOR 1 SHIELD CIRCUIT	N/A
