Connector "B" Disconnected (4-Wire Connector)

  1. Check continuity between terminals No. 2 and 4 of connector "B" while depressing the CHECK switch. If continuity is present, circuit is okay. Go to step 2). If continuity is not present, replace mode select switches. See Figure .
  2. Check continuity between terminals No. 2 and 3 of connector "B" while depressing the LIST switch. If continuity is present, circuit is okay. Go to step 3). If continuity is not present, replace mode select switches.
  3. Check continuity between terminals No. 2 and 5 of connector "B" while depressing the RESET switch. If continuity is present, circuit is okay. If continuity is not present, replace mode select switches.
