Throttle Body (Standard) Connector End View (D6701A)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 1/13951/97

Part Description: Not Available

Connector No: D6701A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Throttle Body Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Throttle Body Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K447

GN/GY

0.75

ETC MOTOR (+)

N/A

K448

WH/YE

0.75

ETC MOTOR (-)

N/A

K122

BK/GN

0.75

TP 2 SIGNAL

N/A

K856

GY/YE

0.75

5 VOLT SUPPLY

N/A

K22

BK/RD

0.75

TP 1 SIGNAL

N/A

K922

BN/YE

0.75

TP SENSOR RETURN

N/A

⁽¹⁾	Pins not listed are not used for this connector
