Switch-Seat Belt Buckle-Center (Standard) Connector End View (D2882A)

Harness-Family: Seat_Center

Color: GRAY

Gender: MALE

Part Number: 7282-6443-40

Part Description: Not Available

Connector No: D2882A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Switch-Seat Belt Buckle-Center Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Switch-Seat Belt Buckle-Center Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z107

0.5

GROUND

PASSENGER DOUBLE SEAT

R50

0.5

CENTER SEAT BELT BUCKLE SWITCH SENSE

PASSENGER DOUBLE SEAT

⁽¹⁾	Pins not listed are not used for this connector
