Starter C1 (Standard) Connector End View (D6637A)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 2098198-5

Part Description: Not Available

Connector No: D6637A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Starter C1 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Starter C1 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

T750

2.5

STARTER RELAY OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
