Speaker-Left Front Door (Standard) Connector End View (D5908A)

Harness-Family: Door_Front_Left

Color: BLACK

Gender: FEMALE

Part Number: 1/10275/87

Part Description: Not Available

Connector No: D5908A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Speaker-Left Front Door Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Speaker-Left Front Door Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

X201

0.75

LEFT FRONT SPEAKER (+)

N/A

X291

YE/BK

0.75

LEFT FRONT SPEAKER (-)

N/A

⁽¹⁾	Pins not listed are not used for this connector
