Solenoid-Oil Pump (Standard) Connector End View (D2555A)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 805-120-531

Part Description: Not Available

Connector No: D2555A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Solenoid-Oil Pump Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Solenoid-Oil Pump Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

G62

BN/GY

0.75

OIL PRESSURE SOL CONTROL

N/A

Z916

BK/VT

0.75

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
