Radio C5 (Premium) Connector End View (D3843E)

Harness-Family: IP

Color: RED

Gender: FEMALE

Part Number: 1/13083/85

Part Description: Not Available

Connector No: D3843E

Option: PREMIUM

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Radio C5 Connector End View (PREMIUM)

GCWD1252746

Courtesy of CHRYSLER

Fig 2: Radio C5 Component Location (PREMIUM)

GCWD1293405

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

J220

BK

0.81

COAX CABLE A LVDS CAMERA REAR SIG

SURROUND VIEW CAMERA

⁽¹⁾	Pins not listed are not used for this connector
