Horn (Standard) Connector End View (D5905A)

Harness-Family: Body_Front

Color: GRAY

Gender: FEMALE

Part Number: 1/09889/96

Part Description: Not Available

Connector No: D5905A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Horn Connector End View (Standard)

GCWD1000534

Courtesy of CHRYSLER

Fig 2: Horn Component Location (Standard)

GCWD1293569

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

A

Z298

BK/VT

0.75

GROUND

N/A

B

X2

WH/VT

0.75

HORN CONTROL OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
