Fuse Holder 50A (Standard) Connector End View (D845A)

Harness-Family: Body_Rear

Color: BLACK

Gender: FEMALE

Part Number: 1/01412/87

Part Description: Not Available

Connector No: D845A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Fuse Holder 50a Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Fuse Holder 50a Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A870

RD/BK

FUSED B(+)

AUXILIARY SWITCHES

A922

FUSED B(+)

AUXILIARY SWITCHES

⁽¹⁾	Pins not listed are not used for this connector
