Contact Plate Right C2 (Standard) Connector End View (I6618B)

Harness-Family: Body_Sl_Doors_Jpr

Color: WHITE

Gender: FEMALE

Part Number: 1/23666/80

Part Description: Not Available

Connector No: I6618B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Contact Plate Right C2 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Contact Plate Right C2 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z918

0.5

GROUND

CARGO VAN

P404

GY/DB

0.5

RIGHT REAR PASSIVE ENTRY HANDLE SWITCH SENSE

CARGO VAN

Z918

0.5

GROUND

CARGO VAN

⁽¹⁾	Pins not listed are not used for this connector
