Coil-Ignition 2 (Standard) Connector End View (D5205A)

Harness-Family: Injector

Color: BLACK

Gender: FEMALE

Part Number: 805-121-521

Part Description: Not Available

Connector No: D5205A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Coil-Ignition 2 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Coil-Ignition 2 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K17

DB/BG

COIL CONTROL 2

N/A

F343

BN/WH

FUSED ASD RELAY OUTPUT

N/A

Z914

0.35

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
