Antenna-Radio Am/Fm (Standard) Connector End View (D5901A)

Harness-Family: Body_Right

Color: WHITE

Gender: MALE

Part Number: 1/13053/90

Part Description: Not Available

Connector No: D5901A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Antenna-Radio Am/fm Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Antenna-Radio Am/fm Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

0.81

ANTENNA SIGNAL

HIGH ROOF

⁽¹⁾	Pins not listed are not used for this connector
