Antenna-Passive Entry 5 (Standard) Connector End View (D2598A)

Harness-Family: Fascia_Rear

Color: BLACK

Gender: FEMALE

Part Number: 1-1438608-5

Part Description: Not Available

Connector No: D2598A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Antenna-Passive Entry 5 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Antenna-Passive Entry 5 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

D928

OG/DB

0.5

PASSIVE ENTRY ANTENNA 5 SIGNAL

CARGO VAN EXCEPT TRAILER TOW

D929

WH/BN

0.5

PASSIVE ENTRY ANTENNA 5 RETURN

CARGO VAN EXCEPT TRAILER TOW

⁽¹⁾	Pins not listed are not used for this connector
