Antenna-Passive Entry 2 (Standard) Connector End View (D3102A)

Harness-Family: Door_Front_Right

Color: BLACK

Gender: FEMALE

Part Number: 1-1438608-5

Part Description: Not Available

Connector No: D3102A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Antenna-Passive Entry 2 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Antenna-Passive Entry 2 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

D922

WH/BK

0.5

PASSIVE ENTRY ANTENNA 2 SIGNAL

N/A

D923

WH/DB

0.5

PASSIVE ENTRY ANTENNA 2 RETURN

N/A

⁽¹⁾	Pins not listed are not used for this connector
