Antenna-LTE2/4G (Standard) Connector End View (D5900D)

Harness-Family: IP

Color: VIOLET

Gender: FEMALE

Part Number: 1/13080/99

Part Description: Not Available

Connector No: D5900D

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Antenna-Lte2/4g Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Antenna-Lte2/4g Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

J240

1.1

CABLE 4G CELL

TELEMATICS

⁽¹⁾	Pins not listed are not used for this connector
