Airbag-Side Thorax-Left (Standard) Connector End View (D6679A)

Harness-Family: Seat_Left

Color: BLACK

Gender: FEMALE

Part Number: APPI0001721

Part Description: Not Available

Connector No: D6679A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Airbag-Side Thorax-Left Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Airbag-Side Thorax-Left Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Case

Z107

YE/GN

0.5

GROUND

N/A

0.5

LEFT SEAT THORAX SQUIB 1 LINE 1

N/A

0.5

LEFT SEAT THORAX SQUIB 1 LINE 2

N/A

⁽¹⁾	Pins not listed are not used for this connector
