Airbag-Passenger Squib (Standard) Connector End View (D6665A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 1/07137/97

Part Description: Not Available

Connector No: D6665A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Airbag-Passenger Squib Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Airbag-Passenger Squib Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R44

BN/GY

0.5

PASSENGER SQUIB 1 LINE 1

N/A

R42

0.5

PASSENGER SQUIB 1 LINE 2

N/A

⁽¹⁾	Pins not listed are not used for this connector
