Actuator-Blend Door-Left (Standard) Connector End View (D53A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 1456985-3

Part Description: Not Available

Connector No: D53A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Actuator-Blend Door-Left Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Actuator-Blend Door-Left Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

C26

WH/GY

0.35

REFERENCE VOLTAGE SUPPLY

A/C

C34

BK/VT

0.35

COMMON DOOR DRIVER

A/C

⁽¹⁾	Pins not listed are not used for this connector
