Switch-Seat Belt Buckle-Passenger (Standard) Connector End View (D2283A)

Harness-Family: Seat_Right

Color: GRAY

Gender: MALE

Part Number: 7282-6443-40

Part Description: Not Available

Connector No: D2283A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Switch-Seat Belt Buckle-Passenger Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Switch-Seat Belt Buckle-Passenger Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z107

0.5

GROUND

N/A

R60

0.5

PASS SEAT BELT BUCKLE SWITCH SENSE

N/A

⁽¹⁾	Pins not listed are not used for this connector
